1.2080 steel plate, also known as ASTM D3 steel, is a very versatile tool steel. The steel plate is manufactured in accordance with different international standards such as ASTM, DIN and JIS, ensuring its high quality and performance. Its chemical composition includes carbon, manganese, phosphorus, silicon, chromium, vanadium, molybdenum and nickel, which work together to provide excellent mechanical and physical properties.
It is a high-carbon, high-chromium tool steel with excellent wear resistance. The steel has good dimensional stability, high hardness and high strength, and is widely used in high stress cutting, sheet metal punching tools, shear blades for cutting, deep drawing tools, stone processing tools, paper and plastic cutting tools, sheet shear knives, pressure pads, highly wear-resistant plastic molds.
Product Basic Information:
Chemical Elements :
| Standard |
C |
Si |
Mn |
S |
P |
Cr |
Ni |
Cu |
Co |
|
GB/T 1299-1985 |
2.00/ |
≤ |
≤ |
≤ |
≤ |
11.50/ |
≤ |
≤ |
≤ |
Mechanical Properties:
| Annealing |
≤550°C , air cooling, HB:269-217 |
|
Quench |
950-980°C, oil cooling, HRC: 59-63 |
|
Backfire |
180-200°C, backfire at 1 time, each time for 2 hours, HRC:60-62 |
|
320-350°C, backfire at 1 time, each time for 2 hours, HRC:57-58 |
AISI Type D3 cold working tool steel is oil quenched; Small section austenitizing can be quenched with real air. Therefore, tools made of type D3 cold work tool steel are prone to become brittle during hardening. Type D2 tool steel is the most commonly used type D steel. D3 cold work steel contains 1.5-2.35% carbon and 12% chromium.
Application
Polished surface
Packing & Delivery
Our Service
FAQ:
1.What is D3 steel?
D3 is a high-carbon, high-chromium, oil-hardening tool steel that is characterized by a relatively high attainable hardness and numerous, large, chromium-rich alloy carbides in the microstructure. These carbides provide good resistance to wear from sliding contact with other metals and abrasive materials.
2.What is 1.2080 material?
1.2080 is a common tool steel under the ledeburitic 12% chromium steels and is used for the following applications: high-performance blanking dies, punching tools, punch, shear blades, knives Baking & head temple, broaches, drawing tools, drawing dies, ring rolling , wood cutter.
